Automatic PLC Control No.914-610 Type K Span Roll Forming Machine

With Max Span 38 Meters

Simple introduction of machine

• The structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding.
• It has the ability of strong loading and stable operation when running the machine.
• All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.
• We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .　　　
• It is very easy to install the equipment and suitable for producing in the factory.
• The machine has features of low noise and high efficiency.

Details of main machine

Arching machine

Introduction of Cutting

• Machine adopt hydraulic after cutting
• Cutting after forming: Cut the sheet after roll forming to required length
• Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.
• Material of blade: CR12with heat treatment
• Length measuring: Automatic length measuring
• Tolerance of length: 3m+/- 1.5mm

Manual de-coiler

• Dimensions: 1700mm*1000mm*800mm
• Width of feeding: 1000mm
• Capability: 5 Ton
• Inter diameter: 550-610mm
• Mode of expand &fight: inner expand &fight by manual
• Way of feeding: manual

Control panel Panasonic

• Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase (this is can depend on customer request)
• Automatic length measurement
• Automatic quantity measurement
• Computer used to control length & quantity.
• Machine will automatically cut to length and stop when required quantity is achieved
• Length inaccuracy can be amended easily.
• Control panel: Button-type switch and touch screen
• Unit of length: millimeter (switched on the control panel)

Hydraulic station and manual out table

• Hydraulic station power: 4kw
• Hydraulic pressure: 12Mpa
• Jointed by 60mm*40mm tube
• Size: 1.0m long*0.8mwide*0.6-1mhigh
• One out table with two support roller
• Electric Seaming Machine: one unit main power: 0.75KW

Technological process

Decoiling—feeding—roll forming----cut to length—product packing manual---arching---seaming

Composition of machine

Sme pictures of machine

Application

K Span arched roof, k span roofing, large span roof, no-girder roof panel
